ELECTRIC WATER PUMP & FAN DIGITAL CONTROLLER KIT (#8002)
Provides optimum control of Davies, Craig 12 / 24 Volt Electric Water Pumps and Electric Fans. Suits EWP®80, EWP®115, EWP®130, EWP®150, Thermatic® / Electric Fans and billeted style Electric Water Pumps.
The controller offers enhanced appearance, slimmer and the seven-pin plug is safely tucked away, out of sight at the base of the Controller. It has 2 mounting options:
- Nylon Plate
The EWP®/Fan Digital Controller has two specific functions:
- Will manage the operation of the EWP® by varying the speed of the pump in response to the coolant temperature
- Manage control of your electric engine fan.
The Controller has a push-button to lock in any temperature from 40°C (104°F) to 110°C (230°F). It’s recommended you set/target the Controller to closely match your engine’s existing thermostat temperature.
The Digital Controller will operate the engine’s electric fan automatically once the engine has reached +3°C (+5.4°F) above the targeted / set temperature. Another significant benefit is that the Controller allows the EWP® & Fan to run on after ignition shutdown for either 3 minutes or -10°C (-14°F) of set set / target temperature to eliminate heat soak.
